Product Summary

The optical transceiver PT7320-51-1W is compliant with the Small Form-Factor Pluggable (SFP) Multi-Source Agreement (MSA) and SFF-8472. It offers previously unavailable system cost, upgrade, and reliability benefits by virtue of being hot-pluggable.

Parametrics

PT7320-51-1W absolute maximum ratings: (1)Storage Temperature Tstg: -40 to +85 ℃; (2)Operating Temperature TOP: PT7320-51-1W(+): 0 +70; PT7320-52-1W(+): -40 to +85℃; (3)Input Voltage - GND: Vcc V; (4)Power Supply Voltage Vcc-Vee: -0.5 +3.6 V.

Features

PT7320-51-1W features: (1)Transceiver unit with independent, 1310nm MQW FP Laser diode transmitter; InGaAs PIN photodiode receiver; (2)Compliant with SFP MSA and SFF-8472 with duplex LC receptacle; (3)Compliant with 1.25 Gbps 1000Base-LX Ethernet; (4)Compatible with 1.063 Gbps Fiber Channel; (5)Digital diagnostic monitoring; (6)Hot-pluggable; (7)Metal enclosure for lower EMI; (8)+3.3V Single power supply; (9)Operation data rate from 100Mb/s to 1.27Gb/s; (10)Qualified to meet the intent of Bellcore reliability practices; (11)LVPECL logic interface simplifies interface to external circuitry; (12)LVTTL logic level RX LOS; (13)With pull de-latch; (14)Links of 10 km with 9/125 μm single mode fiber (SMF) of maximum interconnect distances; (15)Complies with RoHS directive (2002/95/EC).

Diagrams

PT7320-51-1W block daigram
