Product Summary
The BCM4704KPBG is a dual-band wireless networking processor. The BCM4704KPBG 3 wireless networking processor is high-performance, low-power System On a Chip (SoC) devices designed to support all IEEE wireless networking standards. The BCM4704KPBG offers features such as simultaneous dual-band operation, an expandable platform, and fast time-to-market that differentiate end products. Rich in integrated hardware and software features, the BCM4704KPBG designs are optimized for use in IEEE 802.11a/g access points and routers.
Features
BCM4704KPBG features: (1)10/100 Ethernet MAC with MII for WAN and LAN connectivity; (2)PCI 2.3 host interface (32-bit/33-MHz); (3)Integrated 2-port USB hub; (4)12-Mbps USB 1.1 host and device interface; (5)V 92 codec, audio codec, IR, and GPIO interfaces; (6)SDRAM controller. 32-bit/133-MHz SDRAM controller. DDR and SDR support. From 8 MB to 512 MB capacity; (7)16-bit expansion bus; (8)Dual 16550-compatible UART; (9)0.13u low-power 1/2/3.3V design; (10)BCM4703 cost-reduced version available. Excludes USB, V.92 codec, audio codec, and IR interfaces, and with 8-bit expansion bus.
Diagrams
 |
