AP1084DL-13

TO-252, fixed-mode regulator, 5.0A , 1.4V, Built-in Thermal Shutdown, Fast Transient Response

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~10.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~10.00

PartNumber:: AP1084DL-13

Brand:: Diodes Incorporated - Diodes | Pack: TO | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Daisy's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-19

From Other Seller

Part Number:AP1084DL-13
US $0.10 - 10.00
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AP1084DL-13 is a low dropout positive adjustable or fixed-mode regulator with 5.0A output current capability. The product is specifically designed to provide well-regulated supply for low voltage IC applications such as high-speed bus termination and low current 3.3V logic supply. The AP1084DL-13 is also well suited for other applications such as VGA cards. The AP1084DL-13 is guaranteed to have lower than 1.4V dropout at full load current making it ideal to provide well-regulated outputs of 1.25 to 3.3V with 4.7 to 12V input supply.

Parametrics

AP1084DL-13 absolute maximum ratings: (1)DC Supply Voltage: -0.3 to 12 V; (2)Storage Temperature: -65 to +150℃; (3)Operating Junction Temperature Range: 0 to +125 ℃; (4)Maximum Junction Temperature: 150 ℃.

Features

AP1084DL-13 features: (1)1.4V Maximum Dropout at Full Load Current; (2)Built-in Thermal Shutdown; (3)Output Current Limiting; (4)Adjustable Output Voltage or Fixed 1.5V, 1.8V, 2.5V, 3.3V, 5.0V; (5)Fast Transient Response; (6)Good Noise Rejection; (7)Lead-Free Package: TO252-3L, TO263-3L, and TO220-3L; (8)TO252-3L: Available in “Green” Molding Compound (No Br, Sb) ; (9)Lead Free Finish/RoHS Compliant for Lead Free products.
